I’ve seen a lot of posts out there for the error message we had but no actual solutions for our particular issue.
If you are attempting to install a new instance of SQL Server on your failover cluster, do make sure you are not installing into the Root folder of C:\ClusterStorage\<symlink>. You must make sure you create another directory underneath (We disabled inheritance too).
You probably landed here due to Googling this:
The following error has occurred:
Updating permission setting for folder ‘C:\ClusterStorage\<symlink>\Data\MSSQL13.<DBNAME>\MSSQL\DATA’ failed. The folder permission setting we supposed to be set to ‘D:P(A;OICI;FA;;;BA)(A;OICI;FA;;;SY)(A;OICI;FA;;;CO)(A;OICI;FA;;;S-1-5-80-xxxxxxx)’.
Click ‘Retry’ to retry the failed action or click ‘Cancel’ to cancel this action and continue setup.
The resolution to this problem for us was super super simple. We were not running the installer “As Administrator”. If you are running into this issue try running the installer As Administrator.
If you are taking over an Active Directory or just trying to run cleanup on one that you currently manage, one of the tasks you will probably want to perform is to check to see which of the built-in schema ExtensionAttributes are in use.
If you don’t have ExtensionAttributes 1-15 in your On Premises Active Directory you will need to extend your schema for Exchange Server.
The script below has also been added to my github.
We ran into an issue with Macs connecting to our file services while attempting an upgrade on a Microsoft Clustering Services File Services on Server 2012R2.
Two 2012R2 Servers/Two 2016 Servers, with the following Roles/Features Installed:
ROLES – File and Storage Services:
File Server Resource Manager
Two Virtual Machines running 2012R2, with Microsoft Clustering Services, with multiple File Server Roles. Everything works with the Macs connecting to these Clustered File Services while running 2012R2. The cluster level is also 2012R2.
However, after adding a 2016 Server into this Microsoft Cluster, and failing over one of the file server roles to it, the Macs can no longer connect to that file server. They receive a message stating:
There was a problem connecting to the server “”. Check the server name or IP address, and then try again. If you continue to have problems, contact your system administrator.
If you migrate the file server role back to a server running 2012R2 the Mac can once again connect.
I plan to come back to this blog to post a more detailed writeup. I was passed on a lot of information that I haven’t seen but I will try to best to explain what I believe is happening.
When a 2016 Server is added to a 2012R2 only cluster, the cluster moves into “Mixed Mode” to allow both Operating Systems to function. Now Microsoft states you should not stay in this mode very long, from what I’ve seen thrown around no more than 4 weeks.
This is hearsay from packet captures but when a Mac tries to connect to the File Services running on 2016 Server while in mixed mode it supposedly connects on SMB 3.1.1, but then something in the network stack wants to downgrade the connection to SMB 2.0, and the Macs cannot follow it and therefore cannot connect to the server.
However, after removing the 2012R2 servers, and then upgrading the Cluster Level to 2016, the Macs can then connect again.
I’m still doing some troubleshooting and this post will be updated.
The SRV records for KMS in DNS can be found by launching a command prompt and entering “nslookup”.
Then run: “set type=all” so all records are returned.
Then the record you want to look up is: “_vlmcs._tcp.domain.suffix”
This should return all of the SRV records for KMS services. This is an important area in DNS to watch because if boxes can add themselves to DNS, anyone who installs the Volume License Services could get a record entered here.
In this particular example we have three SRV records.
We ran into an issue updating our Domain Controllers from Windows Update. This appears to be profile based at first troubleshooting. A different Domain Administrator could pull down updates without any issue.
Still investigating… but if google directs you here, try another DA account.
WAP Server Replacement: Use whatever mechanisms you have through your load-balancing infrastructure to drain one of the WAP servers so nobody is accessing it.
In Server Manager launch “Remote Access Management”
Verify you see the number of Clustered WAPs servers you should here.
You can also verify this with PowerShell by running the following command in an Administrative Powershell: Get-WebApplicationProxyConfiguration.
Look at the “ConnectedServersName” field, here I have two.
Remove the box that you are currently logged into from the ConnectedServersName property object by running the following PowerShell: Set-WebApplicationProxyConfiguration -ConnectedServersName ((Get-WebApplicationProxyConfiguration).ConnectedServersName -ne ‘servername.domain.suffix’)
[-ne means not equal, you want to put the server you want to remove in place of ‘servername.domain.suffix’]
You can then verify by running Get-WebApplicationProxyConfiguration again and see that the server has disappeared.
I only have two WAPs so at this point both nodes are still servicing requests but only one node is left in the settings. You can now shutdown the node you removed and bring up a new 2019 server with the same name/IP and bind into the already existing AD Object.
Once this box is up login with a Domain Admin account and Add Roles/Features and add the “Remote Access” Server Role
Choose “Web Application Proxy” on the Role Services tab. You may be prompted to accept installing additional features, go ahead and click Add Features.
Once this is complete and before you launch the Web Application Proxy Wizard, we need to get the ADFS certificate loaded onto this box.
Go to another ADFS node that has the certificate and export the certificate. This certificate should be in the Personal\Certificates area of the Local Machine.
Export the certificate
Import the Certificate on the server you are currently working on into the Personal\Certificates Certificate Store of the Local Machine.
Now you are ready to Open the Web Application Proxy Wizard”
Choose the Certificate we imported it should be in the drop down.
Before you hit “Configure” depending on how your DNS is configured you need to make sure the WAP server can get to your adfs servers using the primary DNS name. For us this involved some HOSTS file magic.
Click “Configure” and you should see the Web Application Proxy Configuration completed successfully.
VERIFY everything is up and working and this new node is servicing requests. You should also see now that Remote Access Manager and the Powershell configuration once again shows two nodes participating.
Repeat this process to take down any other WAPs.
ADFS Server Replacement:
Login to any of the federation servers that are not currently the Primary Node. You will know this by launching the ADFS Management Console.
Go to Server Manager, Manage -> Remove Roles & Features
Uncheck Active Directory Federation Services.
Click Next, Next, Next…… Finish
Reboot to finish the removal process.
Shutdown this box and bring up another box with the same name, IP, configuration. Bind it to the domain and take over the old AD object.
Login as a “Domain Admin” and Go to Server Manager, Add Roles & Features
Click “Install” and then configure the federation services on this server.
Specify the FQDN of the Primary Node of your Active Directory Federated Services. (Servername.Domain.Suffix)
Note** Like we did on the WAP servers make sure the certificate is loaded onto the Local Machine Personal Certificates Store on this box before continuing.
Choose the SSL Certificate you imported
Specify a domain user account or group managed service account. In this particular example this is a domain user account. If you use a domain user account make sure it is a local administrator of the server.
[I’m checking on this local administrator may not be needed anymore].
NOTE** If you are locking down firewall rules, before configuration can run verify that Port 80 can be accessed on the primary node from this server.If you receive DNS errors here it could be Port 80, and not actually DNS.
Verify this node is now accepting requests.
Perform these steps on every other ADFS node that is not the primary node. Once complete, continue to migrate Primary Node to a node that was already replaced so primary node can be upgraded.
Migrate Primary Node to a Replaced Node:
Pick a node that has already been replaced that you want to migrate the primary node to. On this node run the following:
Set-AdfsSyncProperties -Role PrimaryComputer
If you perform a Get-AdfsSyncProperties both before and after you should see the role change.
Now you need to go the original primary node owner and run the following:
You will want to wait about 5 minutes and make sure when you run Get-AdfsSyncProperties that you are actually seeing a successful last sync come from the new primary node before you take down the original primary node.
You can now repeat the process listed here to replace the original primary node. If you want to migrate the primary node back when you are done you can follow these instructions again.
There are many security risks with running Active Directory. In the Year 2022, one of these is still running your Active Directory with unsigned/simple ldap binds.
If you don’t already have a PKI environment setup you should probably work to set one up so you can get certificates on your Domain Controllers that are trusted by your businesses devices so unsigned/simple binds can be retired.
A script I’ve found very helpful for monitoring the Domain Controller firewall logs for these events is located here:
